Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: Skyscanner
  • Model Number: TX-5030C
  • Tunnel Size: 500*300mm
  • Conveyor Speed: 0.2m/s
  • Max. conveyor load: 150kg
  • Penetration: 36mm steel plate
  • Power supply: 220V AC
  • Anode voltage: 80KV(adjustable)
  • Warranty: 12 months
  • x ray baggage scanner: x ray baggage scanner
  • Sample test: Support

Packaging & Delivery

Packaging Details x-ray baggage scanner is carton package
packing size: L1850*W830*H1500mm
weight: 500kg
Delivery Time within 3 days after payment confirmed

high penetration x ray baggage screening machine good quality scanner











Product Description

x-ray inspection machine Features



1. Energy saving design. Auto-induction (optional).

2. A key shutdown control. Turn off the machine only need one step: revolves the key.

The equipment automatic security close-down, does not need complex many steps, is simpler.

3. Environmental design. Lead curtain with protective film, avoid lead pollution.

4. Network interface. Could be connect local area network and support multi-terminal

check baggage at same times.

5. Safety ray. Transmit ray under automatic control, avoids the miss.





Specification



                       Contents

                            Index

Technical Data

Model Name: 5030A

Tunnel Size: W500*H300mm

Conveyor Speed: 0.22m/s

Conveyor Max Load: 150 kg

Resolution: 0.787mm metal line

Steel Penetration: 36mm armor plate

Film Safety: For ISO 1600

Maximum leakage radiation: <0.05µ GY/H

X-ray Generator

OrientationVertically Upward

Tube Current0.4~0.5MA(adjustable)

Anode Voltage80KV(adjustable)

Angle80°

Operating Environment

Storage Temperature: -20ºC to 60ºC

Operating Temperature: 0ºC to 45ºC

Relative Humidity: 20 -90%non-condensing

System Power:  220 VAC(±10%) 50±3HZ

Power wastage:  1.0KW (Max)

Noise:   <55DB





Application

Security checkpoints; Commercial buildings;

Government buildings; Hotels; Embassies;

Factories (to find needle in food, clothing, shoes, bags);

Courthouses; Prisons; Schools; Military installations; Convention centers.

Excellent system for schools,  hotels,  convention centers and event-based security

requirements.







Packaging & Shipping



Packing details

carton packing

1 set/ctn

Packing Size: (L)1850*(W)830*(H)1500mm

Gross Weight:500kg

Payment  terms

T/TWestern Union, Money Gram, Cash, Escrow,L/C

Shipping methods

By air   (5-7daysmost expensive)

By express (3-7daysmore expensive)

By sea    (15-28days, cheapest)









Company Information

    Skyscanner Electronics provides the public with security systems, aviation security, rail

security and station terminal security which are used in industrial manufacturing, shipbuilding

industry, metal processing, electronics factories, food processing, sports and entertainment .
